UEM1P5-compteur d'énergie triphasé pour TC 1/5A avec communication intégrée

• For 1 or 5A CT
• Programmable CT ratio
• Fully bi-directional 4-quadrant measurements for all energies and powers
• For 3 / 4 wire networks with balanced or unbalanced load
• Class B according to EN 50470-3 (MID)
• Tariff input
• 2 S0 outputs for energy pulse emission
• LCD display with 8 main digits
• IR optical port for communication with external modules
• Available with MID certification

General Features

4 DIN modules energy meter for the energy measurement in industrial and civilian applications, available with MID certification suitable for billing. Combined with different external modules, the meter can communicate with other systems. COM modules are available for the most common field protocols. Besides the energy, the meter can measure the main electrical parameters and makes them available on the IR port. The LCD display shows the energies and the instantaneous powers.

The meter is built according to EN 50470-1 standard. The active energy is compliant with IEC/EN 62053-21 class 1, but for MID certified devices, it moreover fulfills class B requirements according to EN 50470-3. The accuracy of reactive energy is compliant with IEC/EN 62053-23 class 2.

Wide backlighted LCD display with clear graphic symbols comprehensible at a glance. Metrological LED on the front panel and sealable terminal covers. Available versions with different voltage working range for the connection on 3 or 4 wire networks, suitable for balanced or unbalanced loads.

The analysis of the MTBF values, the accurate selection of components, and the reduction of internal working temperatures, together with strict production and control standards, guarantee a product with excellent quality and long-lasting reliability.
